Product Description
Part number: SM68RFE
Fits: 68RFE
Fits: 68RFE
Build your own 68RFE rebuild kit: choose the parts that match the transmission on your bench and leave out what you don't need. This builder has 27 choices: 1 required (Your Overhaul/Seal Kit) and 26 optional upgrades and add-ons.
Brands offered in this kit include Alto, Raybestos, Sonnax, TransGo, Superior, Dura-Bond, Lubegard, Dr. Tranny, ATSG and Rostra.
What you can choose
- Your Overhaul/Seal Kit (required): Gasket & Seal Overhaul Kit
- Fiber/Farpak Pan Gasket: Oil Pan Gasket - Fiber/Farpak; Oil Pan Gasket - Molded Rubber
- Molded Rubber Clutch Piston Kit: Molded Rubber Piston Kit
- Sump Filter: 2WD Sump Oil Filter; 4WD Sump Oil Filter
- Spin-On Oil Filter: Cooler Return Spin-On Oil Filter
- Friction/Clutch Kit: High Energy Friction Module - Raybestos; High Energy Friction Module w/ High Capacity Overdrive(14 Borg OD Frictions and TransGo Pressure Plate #RFE-PP-ODHP) - Raybestos; GPZ Friction Module - Raybestos; GPZ Friction Module w/ High Capacity Overdrive(14 Borg OD Frictions and TransGo Pressure Plate #RFE-PP-ODHP) - Raybestos; Stage-1/High Energy Combo Red Plate Friction Module - Raybestos; Stage-1/High Energy Combo Red Plate Friction Module w/ High Capacity Overdrive(14 Borg OD Frictions and TransGo Pressure Plate #RFE-PP-ODHP) - Raybestos; Red Eagle/High Energy Combo Friction Module - Alto (with the Smart-Tech housing, choose a standard non-ODHP module)
- Steel Plate Kit: OE Steel Plate Module; Kolene Steel Plate Module
- Master Bushing Kit: Seamless Bushing Kit - DuraBond; Bushing Kit - Sonnax
- Rear/Extension Housing Bushing: Rear/Extension Housing Bushing
- Torrington Bearing Kit: Bearing Kit - Sonnax
- Selective Washer Kit: Selective Washer Kit (11 Washers, 2-4 Drum to Ring Gear Hub)
- Shift Kit: Shift Kit (2007-2011) Transgo (SK45RFE-A); Transmission HD Reprogramming Kit (2007-2018) TransGo (45RFE-HD2-A); 7-Checkball VB Tuneless™ Reprogramming Kit™ (1999-2010) TransGo (RFE-7B-HP); 5-Checkball VB Tuneless™ Reprogramming Kit™ (2011-2018) TransGo (RFE-5B-HP); High Pressure Tuneless™ Reprogramming Kit™ (2019-UP) TransGo (RFE-HP-19UP); Valve Body Shift Kit (2019-UP) TransGo (SK68RFE-19UP)
- Switch Valve Repair Kit: .420 bore - Switch Valve Repair Kit w/ Tool TransGo (RFE-SV420-WT); .453 bore - Switch Valve Repair Kit Without Tool TransGo (RFE-SV453-NT) (Requires Reamer Tool); .453 bore - Switch Valve Repair Kit w/ Tools TransGo (RFE-SV453-WT); .453 bore - Oversized Solenoid Switch Valve & Plug Kit Sonnax (92835-31K) (Fits bores containing OE switch valve with .453" dia. large spool only; requires Sonnax F-92835-TL31 reamer, sold separately); Solenoid Switch Valve Plug Kit Sonnax (92835-02K)
- Low Roller Clutch Sprag: Low Roller Clutch w/ Inner & Outer Race; Low/Reverse Sprag Rebuild Kit - Sonnax (72642SK) (reuses your existing races)
- Smart-Tech Overdrive Clutch Housing: Smart-Tech® Overdrive Clutch Housing Kit - Sonnax (72960-18K) (includes its own OD clutch pack - use a non-ODHP friction module)
- Solenoid Pack/Block: Solenoid Block with CAM Plate (2004-2018); Solenoid Block with CAM Plate (2019-2020); Solenoid Block (White Connector) (2007-2018) Rostra (50298-S)
- Governor Pressure Sensor: Governor Pressure Sensor Transducer
- Speed Sensors Input/Output: Input & Output Speed Sensor Kit (2 Sensors); Single Input/Output Speed Sensor
- Accumulator Piston Kit: HD Accumulator Piston Kit (Sonnax); Billet Dual-Seal Accumulator Piston Kit (TransGo) (not needed with RFE-HP-19UP - pistons included)
- Tub Of Assembly Lube: Dr. Tranny Transmission Assembly Lube - Green Firm; Dr. Tranny Transmission Assembly Lube - Blue Soft; Dr. Tranny Transmission Assembly Treatment by Lubegard; Sonnax Slippery Stick O-LUBE
- HD Inner Retainer Housing: HD Remanufactured Inner Retainer Housing Kit - Sonnax; HD Inner Retainer Housing Kit, New - Sonnax (72554-01K)
- HD Input Drum Snap Ring: HD Input Drum Snap Ring (already included in TransGo HD/HP reprogramming kits)
- Sonnax Pump Gear Bushing: Single Upgraded Pump Gear Bushing - Sonnax
- Underdrive/Overdrive/Direct Clutch Return Spring: Underdrive/Overdrive/Direct Clutch Return Spring
- Input Housing Selective Washer Kit: Input Housing Selective Washer Kit
- Rebuild Manual: 68RFE ATSG Tech Rebuild Service Manual
- Thermal Bypass Valve: Sure~Cool Thermal Bypass System by Superior (STL030) (replaces the stuck wax thermostat; 4-port bypass blocks) (Keeps Temps Down)
Not sure which option fits? Contact us with your vehicle's year and model and your transmission's identification and we'll help you choose.
Dodge HD 68RFE Transmission Super Master Performance Rebuild Kit
RAM 2500 & 3500 w/ 6.7L Cummins Diesel Engines 2007-UP
This Super Master Performance Rebuild Kit for Dodge HD 68RFE transmissions contains all the standard parts required in a complete rebuild, and includes high performance clutches.
