Product Description
Fits: RE5F22A / AW55-50SN
Low stall lockup torque converter for RE5F22A and AW55-50SN transmissions, with 20 splines, codes 433, 437, 43A260 and 43A261.
Specifications
| Overall diameter | 11.20" |
|---|---|
| Bolt pattern | 9" |
| Mounts | 6 pad, 8mm x 1.25 thread |
| Hub | Slotted |
| Pilot diameter | .810" |
| Pilot length | .750" |
| Splines | 20 |
| Stall | Low |
| Codes | 433, 437, 437 Y51, 43A260, 43A261, Y51 43A261 |
| Body diameter | 11.188 in (284.2 mm) |
| Hub internal bushing | No |
| Hub seal groove | No |
| Number of mounts | 6 |
| Mount type | Stepped Pads |
| Pilot OD major (in) | 0.81 |
| Pilot type | Straight |
| Ring gear | No |
| Paint codes | 433 |
| Stamped codes (dye/ink) | 433, 43A260, 43A261 |
| Cooling shroud | No |
| Billet cover | No |
| Turbine internal splines | 20 |
| Lock-up | Yes |
| AW55-50SN | 2004-2006 |
| RE5F22A | 2008-2009 |
| Nissan Quest | 2008-2009, FWD |
| Nissan Maxima | 2004-2006, FWD |
| Nissan Altima | 2005-2006, FWD |
Core Charge
Core charge: $120, already included in the price. The price of this converter includes a $120 refundable core charge. When your new converter arrives, send your old converter back with the prepaid return label we provide (for returns from within the USA), and we will refund the $120 once the core is received and checked.
- Ship the core back within 30 days of delivery for the full refund. Cores shipped 31 to 90 days after delivery get 70% of the core charge back. After 90 days, the core charge is not refunded.
- Outside the USA? The prepaid label only works for returns from within the USA. You can still ship the core back at your own cost to receive the refund.
- The core must be the same type as the converter you bought, complete, and not cracked, cut open or taken apart.
- Drain the fluid, pack it securely, and put your order number in the box.
- We refund the core charge to your original payment method within 5 business days of receiving it.
Contact us before shipping if your core is damaged or you need a new label.
