Product Description
Part number: TK-HMMWV-01
Fits: HMMWV · 4L80E · 6.2L / 6.5L
Fits: HMMWV · 4L80E · 6.2L / 6.5L
Collection of Kent-Moore, Draf, OTC and SPX specialty tools made for military service on Hummer HMMWV heavy duty trucks with 6.2L and 6.5L engines. The tools work with most 4L80E automatic transmissions and GM vehicles with 6.2L and 6.5L engines.
There are 51 total items in the kit, and the tools have never been used.
Specifications
| Fits | Hummer HMMWV, 4L80E, GM 6.2L and 6.5L engines |
|---|---|
| Total items | 51 |
| Condition | Never used |
About this kit
Most of the tools are Kent-Moore and Draf Industries (a Kent-Moore equivalent). At least some are for the 4L80E transmission. The contents below list the tools not shown in the pictured tool list.
What's included
- Tie rod separator
- Yoke seal installer (J-29162)
- Drive transmission handle (Draf 551)
- Power steering pump pulley installer (Draf 553)
- Geared hub input seal inserter (Draf 579)
- Geared hub seal inserter (Draf 580)
- Geared hub socket wrench (Draf 581)
- Governor weight support (J-16313)
- Pilot tube mandrel (J-16314)
- Replacement bushing kit (J-18411)
- Transfer pump end cap socket (J-20548)
- Clutch spring compressor adapter (J-21664)
- Rear bearing pinion remover (J-21786)
- Bearing/bushing remover (J-21786)
- Slide hammer adapter (SPX 8007)
- T27 Torx bit
- Output shaft seal inserter (J-22661)
- Yoke seal installer (J-29162)
- Oil seal installer (J-21359)
- Seal inserter (J-33153)
- Clutch spring compressor (Draf 4670)
- Inner clutch alignment tool (J-24396)
- Bearing and bushing inserter (Draf 576)
- Hydraulic valve lifter remover (J-29834)
- Rack piston steer gear punch (J-21552)
- Bearing/brush remover (Draf 6221)
- Bearing/brush inserter and remover (Draf 6278)
