Product Description
Fits: GM 6L80E / 6L90E / 4L80E and other GM, Ford, Chrysler cases
Heavy duty holding fixture from Superior Machine and Fabrication, designed for the extra weight of the GM 6-speed transmissions (6L80E, 6L90E) and the 4L80E. No adapter is needed for the 4L80E.
It also fits Ford and Chrysler 3, 4 and 6 speed automatics and most common OEM GM or aftermarket cases with service dowel pin hole bosses. The fixture rotates 360° and the swivel base locks with a quick pin in 4 positions (vertical or horizontal).
Specifications
| Fits | Turbo Hydra Matic 180C/3L30, 200, 200C, 200-4R, 250, 250-C, 350, 350-C, 375, 400/3L80, 425, 475, 3L80-HD, 700-R4/4L60/4L60E, 4L80E, 6L80E, 6L90E |
|---|---|
| Rotation | 360°, locks in 4 positions |
| Finish | Machine blue smooth satin powder coat |
| Bench mount | SMAF-020 |
Construction
An additional top clamping screw keeps the heavier GM 6-speed and 4L80E cases from rotating in the fixture. The heavy duty fabricated steel frame will not twist or bend in use. Clamping screws are hardened tool steel with steel adjusting knobs, and the top clamping screws have hardened steel swivel pads to prevent damage to aluminum cases. The finish is machine blue smooth satin powder coat. 100% made in the USA. It is designed for use with the standard bench mount fixture, SMAF-020.
Notes
Heavy duty fabricated steel frame will that will not twist or bend when in use, additional top clamping screw prevents transmission case from rotating with in the fixture due to the heavier weight of the GM 6 speed and 4l80e transmissions.
*No Adapter required for use with 4l80e transmissions*
Mounting base not included
THE BENCH MOUNT IS NOT INCLUDED UNLESS YOU ADD IT TO THE ORDER.
