E4OD Friction Clutch Plate Module (1989-March1997) Raybestos

Product Description

Friction kit for the Ford E4OD, 1989-March 1997, assembled from Raybestos plates. It uses tan OE replacement frictions in most positions, with a graphitic Coast clutch and High Energy Intermediate plates. The contents list below is exactly what is in the box.

Specifications

Other options

For April 1997 and later units, see 3021A. For Stage-1 red plates, see 3021A-STO2.

What's included

• 6 x Low/Reverse, OE replacement: .076 in thick, 6.798 in OD, 72 teeth (R560715)
• 5 x Direct, 2nd design, OE replacement: .077 in thick, 6.389 in OD, 64 teeth (R505130)
• 3 x Overdrive, OE replacement: .077 in thick, 8.69 in OD, 64 teeth (R575120)
• 2 x Coast, Graphitic: .077 in thick, 6.594 in OD, 60 teeth (R575030)
• 3 x Intermediate, High Energy (4R100 except with diode): .074 in thick, 7.793 in OD, 50 teeth (R575140)
• 4 x Forward, hardened core, OE replacement: .077 in thick, 6.365 in OD, 90/96 teeth (R560200)
