E4OD Custom Options Super Master Rebuild Kit (1989-1997)

Product Description

Build your own E4OD rebuild kit: choose the parts that match the transmission on your bench and leave out what you don't need. This builder has 29 choices: 1 required (Overhaul/Seal Kit) and 28 optional upgrades and add-ons.

Brands offered in this kit include Alto, Raybestos, Exedy, BorgWarner, Sonnax, TransGo, Superior, Lubegard, Dr. Tranny, ATSG, Torrington and Fairbanks.

What you can choose

• Overhaul/Seal Kit (required): 1989-1995; 1996-E1997
• Pan Gasket: Fiber/Farpak; Molded Rubber
• Filter: 2WD; 4WD
• Overdrive and Coast Molded Rubber Pistons: Overdrive & Coast Clutch Piston Kit (1989-2004)
• Friction Module: Early High Energy Frictions (1988-March1997) (Alto); Early High Energy Frictions 1989-March1997 (Raybestos); Early High Energy Frictions 1989-MARCH1997 (Exedy); Early Red Eagle Performance Frictions (1988-March1997) (Alto); Early Stage-1 Performance Frictions 1989-March1997 (Raybestos); Late High Energy Friction Module April1997-UP (Alto); Late High Energy Frictions APRIL1997-UP (Exedy); Late High Energy Frictions April1997-UP (Raybestos); plus 2 more
• Steel Module: OE Steel Plate Module (1989-1996); Performance Kolene Steel Module (1989-1996); OE Steel Plate Module (1997 Only) (Fits Early & Late 1997 - Use if You Do Not Know Your Build Month); OE Steel Plate Module (April1997-UP); Performance Kolene Steel Module (April1997-UP)
• Band: Aftermarket; Raybestos; BorgWarner
• Bushing Kit: Master Bushing Kit (1989-E1997)
• Thrust Washer Kit: 1989-6/1991 | 3-Pinion Planet Style; 1989-UP | 3 & 4 Pinion Planet Style; 1989-UP | 4 & 6 Pinion Planets; 1989-UP | 4-Pinion Planet Style
• Torrington Bearing Kit: Torrington Bearing Kit (1989-E1997)
• Overdrive Sprag: 1995-E1997 | 12-Roller; 1989-1994 | 34-Element
• Intermediate Sprag: 34-Element Aftermarket; 45-Element BorgWarner
• Overrun Clutch/Rear Sprag: Overrun Clutch/Rear Sprag (1989-E1997); Overrun Clutch/Rear Sprag (L1997-UP) 17-Roller Style
• Intermediate Servo Piston: Intermediate Servo Molded Piston (1989-2004)
• Overdrive Snap Ring: Upgraded Sure Lock Spiral Overdrive Snap Ring by Sonnax (1989-2004) (included in TransGo SK/HD2 and Zip kits)
• Forward Clutch Hub Snap Ring: Upgraded Forward Clutch Hub Snap Ring by Superior (1989-2004)
• Center Support Snap Ring: Upgraded Center Support Snap Ring by Sonnax (1989-2004)
• Sonnax Upgraded Forward Clutch Piston: Cast-Aluminum Forward Clutch Piston (1989-2004) Sonnax #36434A
• Boost Valve: Line Pressure Modulator Boost Valve by Superior (1989-2004); Line Pressure Booster Kit Sonnax (1989-2004) (skip if you chose a TransGo, Zip or Superior KE4OD-V kit; they include one)
• Shift Kit: Upgraded Shift Correction Kit (1989-2004) Superior #KE4OD; Shift Kit (1989-2004) TransGo #SKE4OD; PowerTow Performance Shift Kit (1989-2004) Fairbanks/Superior #PT4R100; Reprogramming Kit (1989-2004) TransGo #E4OD-HD2; HD Reprogramming Kit (1989-2004) TransGo #4R100-HD2; Zip Kit (1989-2004) Sonnax #E4OD-4R100-ZIP; Upgraded Shift Correction Kit w/ Boost Valve Superior #KE4OD-V
• Assembly Lube: Dr. Tranny Transmission Assembly Lube - Firm Green; Dr. Tranny Transmission Assembly Lube - Blue Soft; Dr. Tranny Transmission Assembly Treatment by Lubegard; Sonnax Slippery Stick O-LUBE
• Pump Assembly: Rebuilt Pump Assembly Cast Coast Drum Type (1989-1997)
• Solenoid Block: Solenoid Block Assembly w/o PWM (1995-1997)
• External Wire Harness Repair Kit: External Wire Harness Repair Kit (1989-1994)
• Accumulator Repair Kit: Accumulator Body Repair Kit by Superior (STP-K040); Accumulator Body Repair Valve (1989-UP) TransGo (E4-VL-LR3)
• Filter Clip: Stay-Put Filter Clip by Superior (STP-K066)
• Rebuild Manual: E4OD ATSG Tech Service Rebuild Manual
• Center Support Bearing Hub Kit: Center Support Bearing Hub Kit (1989-2004) Updated
• Sun Shell: Sun Shell (1989-2005) 2nd Design

Not sure which option fits? Contact us with your vehicle's year and model and your transmission's identification and we'll help you choose.
