Product Description
Part number: CR10L
Fits: A727 / 46RE / 46RH / 36RH
Fits: A727 / 46RE / 46RH / 36RH
Non-lockup torque converter for A727, 36RH, 46RE and 46RH transmissions, with a 1700-2000 stall. It has an 11.625 in body and a ring gear with 130 teeth.
Specifications
| Fits | A727, 46RE, 46RH, 36RH |
|---|---|
| A727 | 1968-1989 |
| A727 (36RH) | 1975-1994 |
| 46RE | 1996 |
| 46RH | 1993-1995, units without lockup |
| 36RH | 1995-1997 |
| Body diameter | 11.625 in (295.3 mm) |
| Hub | Slotted |
| Hub internal bushing | No |
| Hub seal groove | No |
| Mounts | 4 rectangular pads |
| Mount threads | 5/16 x 24 |
| Bolt circle | 10 in |
| Pilot OD major | 1.81 in, arced |
| Ring gear | Yes, 130 teeth |
| Stall | Low (1700-2000) |
| Turbine internal splines | 24 |
| Lock-up | No |
| Cooling shroud | No |
| Billet cover | No |
Notes
MAKE SURE THIS IS THE CORRECT CONVERTER FOR YOUR APPLICATION BEFORE ORDERING.
IF YOU AREN'T SURE CALL TO VERIFY.
46RE (1996) (LOCKUP MUST BE DISABLED)
Core Charge
Core charge: $100, already included in the price. The price of this converter includes a $100 refundable core charge. When your new converter arrives, send your old converter back with the prepaid return label we provide (for returns from within the USA), and we will refund the $100 once the core is received and checked.
- Ship the core back within 30 days of delivery for the full refund. Cores shipped 31 to 90 days after delivery get 70% of the core charge back. After 90 days, the core charge is not refunded.
- Outside the USA? The prepaid label only works for returns from within the USA. You can still ship the core back at your own cost to receive the refund.
- The core must be the same type as the converter you bought, complete, and not cracked, cut open or taken apart.
- Drain the fluid, pack it securely, and put your order number in the box.
- We refund the core charge to your original payment method within 5 business days of receiving it.
Contact us before shipping if your core is damaged or you need a new label.
Product Videos
Custom Field
Transmission Model(s) A727, 46RE, 46RH, 36RH
Core Charge $100 (already included in price)
