Product Description
Part number: GM16401
Fits: 8L45 · 2016-2022
Fits: 8L45 · 2016-2022
Remanufactured torque converter for 8L45 transmissions. It has a 10.050 in overall diameter, a 9.750 in bolt pattern and 27 turbine splines, with a low stall rating. It comes with a torque converter O-ring seal washer.
Specifications
| Part number | GM16401 |
|---|---|
| 8L45 | 2016 - 2022 |
| Details | 10.050" Overall Diameter; 9.750" Bolt Pattern; Mount Plate; 10mm x 1.5 Thread; Flats/Step/Flange Hub; .824" Pilot Diameter; 1.415" Pilot Length; 27 Spline; Low Stall Speed |
| Codes | 24279503; 24280302; 24293013; 24274130; 24285732 |
| Includes | Torque converter O-ring seal washer (1) |
| Condition | Remanufactured |
Core Charge
No core charge. You don't need to return your old converter. If you'd like to send it back anyway, contact us and we may be able to provide a return label (for returns from within the USA).
Product Videos
Custom Field
Transmission Model(s) 8L45
Year Range 2016-2022
Core Charge None
