Product Description
Fits: 8F35 · 2019-2026
Photo: placeholder image, not a photo of this part
Remanufactured lock-up torque converter for 8F35 transmissions. It has a 10.760 in overall diameter, an 8.85 in bolt pattern and 26 turbine splines, with a low stall rating.
Specifications
| Part number | FM14501 |
|---|---|
| 8F35 | 2019 - 2026 |
| Details | Lock-up; 10.760" Overall Diameter; 8.85" Bolt Pattern; 4 Studs; Milled Flats Hub with Bushing; .825" Pilot Diameter; 26 Spline; Low Stall Speed |
| Codes | JM5PNA; JM5PKA; JM5PKC; JM5PKD |
| Condition | Remanufactured |
Core Charge
Core charge: $170, already included in the price. The price of this converter includes a $170 refundable core charge. When your new converter arrives, send your old converter back with the prepaid return label we provide (for returns from within the USA), and we will refund the $170 once the core is received and checked.
- Return the core within 30 days of delivery.
- Outside the USA? The prepaid label only works for returns from within the USA. You can still ship the core back at your own cost to receive the refund.
- The core must be the same type as the converter you bought, complete, and not cracked, cut open or taken apart.
- Drain the fluid, pack it securely, and put your order number in the box.
- We refund the core charge to your original payment method within 5 business days of receiving it.
Contact us before shipping if your core is damaged or you need a new label.
