Product Description
Part number: GPZ100
Fits: TH700-R4 / 4L60 / 4L60E · 1982-on
Fits: TH700-R4 / 4L60 / 4L60E · 1982-on
Raybestos GPZ friction plate for the 3rd, 4th (3-4) clutch in the TH700-R4, 4L60 and 4L60E. It replaces OE 24201132. The plate is .080 in (2.03 mm) thick with a 5.75 in outside diameter, 20 teeth and no groove.
GPZ is Raybestos Powertrain's heavy-duty friction material, built to withstand high stress, high temperatures and repeated cycling. In testing it outperforms OE material by as much as 20%, and its performance improves as the power increases. Made in USA.
Specifications
| Fits | 700R4, 4L60E |
|---|---|
| Years | 1982-up |
| OE number | 24201132 |
| Clutch position | 3rd, 4th |
| Friction material | GPZ |
| Thickness | .080 in / 2.03 mm |
| Outside diameter | 5.75 in |
| Groove | No groove |
| Teeth | 20 |
| Recommended use | Heavy-duty vehicles, commercial vehicles, high-stress driving and enhanced performance applications |
WARNING : This product can expose you to chemicals, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Product Videos
Custom Field
Transmission Model(s) 700R4, 4L60E
Year Range 1982-UP
