Product Description
Part number: A7XH
Fits: Allison 1000 / 2000 / 2400
Fits: Allison 1000 / 2000 / 2400
High-stall torque converter with a billet cover for Allison 1000, 2000 and 2400 series transmissions. High stall here means a 2.05:1 torque ratio, with a single-disc lock-up clutch.
Specifications
| Stall | High (2.05:1 torque ratio) |
|---|---|
| Cover | Billet |
| Lock-up | Single disc |
| Diameter | 13.3 in |
| Bolt circle | 11.5 in |
| Mounting | 6 drilled holes (replaces 6 pad) |
| Hub | Flats, flanged |
| Input splines | 25 |
| Pilot diameter | 1.703 in |
| Codes | 29534832 / 8197 / 8531 / 29543015 / 9521 / 6574 |
