Product Description
Fits February '04-earlier pumps. Does not fit # 29541135 or later pump stators.
Allison® 1000/2000/2400 OE C-1 clutch control valve has a fixed flow rate and no seal at the large spool to prevent hot fluid loss. Sonnax C-1 valve and seal kit 37000-05K controls the fill and exhaust rate of the C-1 clutch as well as reducing loss at the valve bore. The regulation contour of the Sonnax valve provides a controlled fill to reduce harsh engagements common to cold weather, long sit or Reverse to Forward abuse conditions. Controlling the flow rate reduces wear on the C-1 clutch hub. Once the valve is open, the C-1 flow is increased over OE to overcome fluid loss at the drum. The valve also has a PTFE seal to prevent incoming pressure loss to exhaust at the pump casting, which can occur under hot abuse conditions.
- Valve changes the fixed flow rate to a regulated flow rate, reducing wear of the C-1 clutch hub
- PTFE seal prevents C-1 oil from leaking to exhaust
Symptoms
- C1 Clutch hub wear
- Lack of C1 clutch control
- Harsh Forward
- Delayed bump on Forward
Cause
The OE valve has a fixed flow rate, while C1 clutch pressure leaks to exhaust.
Correction
Sonnax C-1 valve and seal kit includes a PTFE seal to prevent C-1 oil loss to exhaust. The new valve changes the fixed flow rate to a regulated flow rate.
Contents
- Valve
- Seal PTFE
