Product Description
Price includes $50 refundable core charge.
| Name | Specs |
|---|---|
| Billet Cover | No |
| Body Diameter Inches | 12.2 |
| Bolt Circle Inches | 10 |
| Codes Metal/Laser Stamped | 659AB |
| Country of Origin (Primary) | US |
| Dimension Height | 7.375 |
| Dimension Length | 13.5 |
| Dimension UOM | Inches |
| Dimension Width | 13.5 |
| Hub to Thrust Surface Inches | 2.22 |
| Hub Type | 4 Flats with Groove |
| Impeller Brazed | Yes |
| Lock-Up Unit | Yes |
| Mount Type | Pad |
| Number of Mounts | 4 |
| Package UOM | Each |
| Pilot Length Inches | 0.86 |
| Pilot OD Major Inches | 1.815 |
| Pump Stall | Low |
| Quantity Per UOM | 1 |
| Remanufactured | Yes |
| Stator Codes | 4753662AA |
| Stator Rotation | Clockwise |
| Stator Spline Count | 27 |
| Stator Sprag Configuration | Rollers |
| Stator Vane Count | 23 |
| Turbine Internal Spline Count | 29 |
| Turbine to Pump Clearance | 0.135 |
| Weight | 45 |
| Weight UOM | Pounds |
| With Ring Gear | No |
