Product Description
This is a complete 4L60E technical repair service manual put together by the ATSG to cover the procedures for transmission inspection, repair, disassembly, rebuilding, diagnosis and troubleshooting. Useful for both professional mechanics and DIYers.
There have been many engineering changes in the 4L60E transmission from 1993 to 2003, so we suggest purchasing that as well to have a complete picture of what is needed in the rebuild.
INFORMATION COVERED IN THIS TECH MANUAL
- Trouble codes and fixes related to the transmission
- Checkball locations
- Bushing locations
- Clutch Clearance Specifications
- Exploded views and diagrams
- Electrical volt and OHMS information
- Endplay check procedures and recommendations
- Solenoid locations and specifications
- Thrust washer locations
- Torrington bearing locations
- Torque Specifications
- Valve body details. Including assembly information and locations of springs and valves
